Additional tamper resistance is provided with the onboard tamper loop that can be used to indicate the removal of the faceplate. SPECIFICATIONS TECHNICAL NOTES Case Dimensions: 232R: 3.75W x 5.25H x 2.50 D 232SE: 3.00W x 4.50H x 1. The under-voltage threshold is set to 8. DOOR-GARD COMMAND AND CONTROL SERIES 212r and 212se Wiring Diagrams and Specifications. Suggested mounting includes gate goosenecks, post, concrete walls, etc. The 212e keypad is designed to monitor the input voltage and this is an indication of under-voltage. The Ruggedized’s housing can be mounted to a variety of surfaces. Entering your code on keypad 2 unlocks the maglock directly.
Iei 212r how to#
There is also an internal sounder that is used to indicate key press feedback. 212i Wiring Diagrams and Specifications TECHNICAL NOTES SPECIFICATIONS: The diagram above shows how to connect two keypads to control a single door. The ruggedized uses an all metal Braille, alpha-numeric keys.
If all 12 keypresses have been verified, the keypad will enter self test mode. Connect the negative (-) lead of your power supply to the terminal strip (TS1) -V input.
The ruggedized R style 212R keypad features a cast aluminum housing and all metal faceplate that has been treated with polyurethane to increase its protection from corrosion. Connect the positive (+) lead of your power supply to the terminal strip (TS1) +V input.
